Product number:

HJ-243316

Brand:

Product name:

bearing

Sizes:

38.1X52.388X25.4

Replacements:

BR 243316 NCS 2416 HJ 243316

Inquiry Subscribe

Fw	38.100 mm
D	52.388 D
C(B)	25.400 mm
r(min.)	1.52 mm
Used with inner ring No.	IR-202416
Basic load ratings : Cr	47.6 kN
Basic load ratings : C0r	72.5 kN
Fatigue load limit : Cu	11.4 kN
Limiting speeds(Grease lub.)	7600 min-1
Limiting speeds(Oil lub.)	12000 min-1
Recommended dimensions - Clearance fit : S(max.)	38.100 mm
Recommended dimensions - Clearance fit : S(min.)	38.085 mm
Recommended dimensions - Clearance fit : H(max.)	52.418 mm
Recommended dimensions - Clearance fit H(min.)	52.388 mm
Recommended dimensions - Tight transition fit : S(	38.075 mm
Recommended dimensions - Tight transition fit : S(	38.059 mm
Recommended dimensions - Tight transition fit : H(	52.380 mm
Recommended dimensions - Tight transition fit : H(	52.349 mm
Shoulder dia. : Da	47.63
(Refer.)Mass	0.154 kg
