Product number:

HK 1412 B

Brand:

Product name:

bearing

Sizes:

14X20X12

Replacements:

5109160 NEW HOLLAND 712 1210 10 TLA 1412 Z

Interchange catalog:

14BTM2012 KOYO FJ-1412 TORR HK1412 NTN HK1412 SKF RHNA142012 SKF TLA1412 IKO 2012102000 F&S 2632007000Z F&S 461702629 AGRI 229240 DAF 229840 DAF 0009812210 DB 569219 ENAS 4063330 FIAT 5109160 FIAT 9931791 FIAT 9983261 FIAT 02966578 IVECO 2966578 IVECO 2966578E-5031-53 IVECO 1408031 JUNG 92046-037 KAWA 0009248005 LIND 06.33719.0010 MAN 06.33719.0063 MAN 3036097M1 MASY 900.317.001.00 PORS 92811608510 PORS 92811608521 PORS 9053041 SKC 8112086 SKC 900.6863 STEY 0635303040 ZF 0635303116 ZF

Inquiry Subscribe

HK1412-B INA

Fw	Under roller diameter	14 mm
D	Outside diameter	20 mm
C	Width	12 mm
Cr	Basic dynamic load rating, radial	7.100 N
C0r	Basic static load rating, radial	8.500 N
Cur	Fatigue load limit, radial	1.030 N
nG	Limiting speed	17.500 1/min
nG Grease	Limiting speed for grease lubrication	10.500 1/min
nϑr	Reference speed	13.500 1/min
≈m	Weight	10,08 g
C1	Width, outer ring	12 mm
rmin	Minimum chamfer dimension	0,8 mm
Tmin	Operating temperature min.	-30 °C
Tmax	Operating temperature max.	140 °C
Lubricant		Without
Lubrication hole		Without
Coating		Without
Sealing		Without
