Product number:

K 16X20X17 H

Brand:

Product name:

bearing

Sizes:

16X20X17

Inquiry Subscribe

Fw	16 mm
Ew	20 mm
Bc	17 mm
Basic load ratings : Cr	12.9 kN
Basic load ratings : C0r	18.5 kN
Fatigue load limit : Cu	2.85 kN
Cage material P/S	S
Limiting speeds(Grease lub.)	18000 min-1
Limiting speeds(Oil lub.)	28000 min-1
Recommended dimensions - Shaft : S(max.)	16.000 mm
Recommended dimensions - Shaft : S(min.)	15.992 mm
Recommended dimensions - Housing : H(max.)	20.020 mm
Recommended dimensions - Housing : H(min.)	20.007 mm
(Refer.)Mass	0.008 kg
