TR 0506 R KOYO

Net price:

13.091 €/pcs

Main warehouse:
On stock
12 pcs

External stock:
On stock
2 pcs

Next delivery:

2026-03-05 - 30 pcs

Product number:

TR 0506 R

Brand:

KOYO

Product name:

bearing

Sizes:

25X62X18.25/14 B:19 R:1.5 r:1.5

Replacements:
K 247/243 09265-25005 SUZUKI 90043-66013 DAIHATSU HR 30305 CN 30305 CN MB025346 MITSUBISHI VKBA 1936 BEARING 2 HR 30305 C 30305 C

Inquiry Subscribe

Product details from catalogue

Drawings:
d 25 mm
D 62 mm
T 18.25 mm
B 17 mm
C 14 mm
r(min.) 1.5 mm
r1(min.) 1.5 mm
Basic load ratings : Cr 56.3 kN
Basic load ratings : C0r 45.8 kN
Fatigue load limit : Cu 6.50 kN
Limiting speeds(Grease lub.) 6700 min-1
Limiting speeds(Oil lub.) 9000 min-1
Load center spread : a 16.3 mm
Constant e 0.55
Axial load factors : Y1 1.10
Axial load factors : Y0 0.60
da(min.) 33.5 mm
db(max.) 35 mm
Da(max.) 53.5 mm
da(min.) 50 mm
db(min.) 58 mm
Sa(min.) 3 mm
Sb(min.) 4 mm
ra(max.) 1.5 mm
rb(max.) 1.5 mm
(Refer.)Mass 0.275 kg
