Product number:

K 58X65X18 H

Brand:

Product name:

bearing

Inquiry Subscribe

Fw	58 mm
Ew	65 mm
Bc	18 mm
Basic load ratings : Cr	34.3 kN
Basic load ratings : C0r	67.1 kN
Fatigue load limit : Cu	10.7 kN
Cage material P/S	S
Limiting speeds(Grease lub.)	4700 min-1
Limiting speeds(Oil lub.)	7300 min-1
Recommended dimensions - Shaft : S(max.)	58.000 mm
Recommended dimensions - Shaft : S(min.)	57.987 mm
Recommended dimensions - Housing : H(max.)	65.029 mm
Recommended dimensions - Housing : H(min.)	65.010 mm
(Refer.)Mass	0.058 kg
