609-2Z-HLC-C3 FAG

Net price:

3.049 €/pcs

Main warehouse:
On stock
640 pcs

External stock:
On stock
14 pcs

Product number:

609-2Z-HLC-C3

Brand:

FAG

Product name:

bearing

Sizes:

9X24X7

Replacements:
609 2Z-C3

Inquiry Subscribe

Product details from catalogue

Drawings:

609-2Z-HLN-C3 FAG

Deep groove ball bearing 60..-2Z, single row, shields, steel sheet metal cage


d Bore diameter 9,00 mm
D Outside diameter 24,00 mm
B Width 7,00 mm
Cr Basic dynamic load rating, radial 3.350,00 N
C0r Basic static load rating, radial 1.430,00 N
Cur Fatigue load limit, radial 43,00 N
nG Limiting speed 38.000,00 1/min
nϑr Reference speed 28.500,00 1/min
≈m Weight 0,01 kg
da min Minimum diameter shaft shoulder 11,00 mm
Da max Maximum diameter of housing shoulder 22,00 mm
ra max Maximum fillet radius 0,30 mm
rmin Minimum chamfer dimension 0,30 mm
D2 Caliber diameter outer ring 20,48 mm
d2 Caliber diameter inner ring 12,10 mm
Tmin Operating temperature min. -30,00 °C
Tmax Operating temperature max. 120,00 °C
f0 Calculation factor 13,00
Logistical code - HLN
Sealing Non-contact Shield on both sides 2Z
Cage steel sheet metal JN
Tolerance class Normal (PN) PN
Dimensional / heat stabilization Rings dimensional stabilized up to 120° SN
Lubricant Grease (L138/customer specific) L138
Fill factor Standard
Radial internal clearance Group 3 (C3), bigger than CN C3
Bore type Cylindrical Z
